SX - 9 4.0 mm Mesh Wire Denfensive Gabion barriers for Military Base
SX-9 Defensive Gabion Barriers: Totally have 12 cells which type is 6 + 6 cells. As an earth-filled barrier, The units are suitable for filling with earth,sand,gravel,crushed rock and other granular material. The units fulfills a wide range of uses,including the construction of protective walls and barriers.
The Specification of SX-9:
| UNIT | HEIGHT | WIDTH | LENGTH | CELL CONDITION |
| SX-9 (Beige) | 3'3" (1.00 M) | 2'6" (0.76 M) | 30' (9.14 M) | 6+6 CELLS |
| SX-9 (Green) | 3'3" (1.00 M) | 2'6" (0.76 M) | 30' (9.14 M) | 6+6 CELLS |
The Technical Specifications from SX-1 to SX-19
| Welded Military Defensive Bastion Wall |
| Model | Height | Width | Length |
| SX-1 | 54"(1.37M) | 42"(1.06M) | 32'9"(10M) |
| SX-2 | 24"(0.61M) | 24"(0.61M) | 4'(1.22M) |
| SX-3 | 39"(1.00M) | 39"(1.00M) | 32'9"(10M) |
| SX-4 | 39"(1.00M) | 60"(1.52M) | 32'9"(10M) |
| SX-5 | 24"(0.61M) | 24"(0.61M) | 10'(3.05M) |
| SX-6 | 66"(1.68M_ | 24"(0.61M) | 10'(3.05M) |
| SX-7 | 87"(2.21M) | 84"(2.13M) | 91'(27.74M) |
| SX-8 | 54"(1.37M) | 48"(1.22M) | 32'9"(10M) |
| SX-9 | 39"(1.00M) | 30"(0.76M) | 30'(9.14M) |
| SX-10 | 87"(2.21M) | 60"(1.52M) | 100'(32.50M) |
| SX-11 | 48"(1.22M) | 12"(0.30M) | 4'(1.22M) |
| SX-12 | 84"(2.13M) | 42"(1.06M) | 108'(33M) |
| SX-19 | 108"(2.74M) | 42"(1.06M) | 10'5"(3.18M) |
The Application for Welded Defensive Barriers:
1. Military Fortifications
Most Army Used Welded Defensive Barrier build up a Military Fortifications, Because it can stack on each other, You can change the width and height by your demands. More easy and flexible.
2. Shooting Range
Nowadays, A lot of people use Military Defensive Barrier to build a shooting range, because its High Strength Defense, more safety.
3. Perimeter Security
Denfesive Barriers can connected together use special joint pin, the length is not limited, they can connected in to a circle to protect something also form a long wall to prevent sand and storm.
The Advantages of Welded Defensive Barrier:
1. Quick Displacements
When you want to use it in another place,Just to move it, It can use many times
2. Easy to repair
As a protection Wall to prevent Bullets and shells, there would be small part damage, Just use one piece of welded wire mesh panel insert into the earth and cover the damage part, it can also work long time.
