Zinc Coated Weave Wire Mesh Retaining Wall For Creek Slope Projects

Name: Zinc Coated Weave Wire Mesh Retaining Wall For Creek Slope Projects
Brand: SHUXIN
Price: 1 USD

China Zinc Coated Weave Wire Mesh Retaining Wall For Creek Slope Projects wholesale

Brand Name : SHUXIN

Model Number : SX-GWC

Certification : ISO, CE, SASO,CO,COC,PVOC

Place of Origin : HB

MOQ : 1000 ㎡

Price : Negotiated

Payment Terms : L/C, T/T, Western Union, MoneyGram, Trade Assurance, Paypal

Supply Ability : 5000 Tons per year

Delivery Time : 15 Working Days

Packaging Details : In Bundle or According to Customer Request

Material : 10% Aluminum - Zinc Alloy Wire

Mesh Hole : 80*100mm

Division : 1 Diaphragm Every Meter

Surface Treatment : Galvanized or PVC Coated

Mesh Wire : 2.2mm to 3.0mm

Selvedge Wire : 2.2mm to 2.7mm

Contact Now

Zinc Coated Strong Weave Gabion Wire Mesh Cages Wall For Creek Slope Projects

Gabion Wire Mesh Cage is made of steel mesh with the type 8 × 10 mesh. The diameter of the wire mesh has normally two types: 2.7 or 3.0 mm. The gabion element is in the shape of block or regular cube size. These special wire bins are made of robust wire, filled with the vibrations at the quarry and transport are accompanied by the lifting straps. The technology provides a seamless transport and storage.

Our gabions materials can also be HDPE coated, which is corrosion resistant and acid resistant. The HDPE coated woven gabions mattresses is a good solution for coastline, which is a undulating terrain and a high level of acid in industrial waste.

Wire Thickness Specification:

Mesh type	8*10cm		6*8cm
Characteristics	Metallic coated	PVC coated	Metallic coated	PVC coated
Mesh openings	83mm x 114mm	83mm x 114mm	64mm x 83mm	64mm x 83mm
Mesh wire	2.7mm (0.106 in.)	3.05mm( 0.120 in.)	2.2mm (0.087 in.)	2.2mm (0.087 in.)
Selvage wire	3.4mm (0.134 in.)	3.8mm (0.150 in.)	2.7mm (0.105 in.)	2.7mm (0.105 in.)
Lacing wire	2.2mm (0.087 in.)	2.2mm (0.087 in.)	2.2mm (0.087 in.)	2.2mm(0.087 in.)

Size of Gabion Box:

Opening(mm)	Wire Diameter(Metal Wire) mm	Wire Diameter (PVC Coated) Inner/Outside(mm)	Strands
60X80	2.0-2.8	2.0/3.0-2.5/3.5	3
80X100	2.0-3.2	2.0/3.0-2.8/3.8	3
80X120	2.0-3.2	2.0/3.0-2.8/3.8	3
100X120	2.0-3.4	2.0/3.0-2.8/3.8	3
100X150	2.0-3.4	2.0/3.0-2.8/3.8	3
120X150	2.0-4.0	2.0/3.0-3.0/4.0	3

Size of Gabion Mattress:

Size				Notes
Length(mm)	Width(mm)	Height(mm)	Unit	volume(m³)
2.00	1.00	0.30	1	0.60
3.00	1.00	0.30	2	0.90
4.00	1.00	0.30	3	1.20
2.00	1.00	0.50	1	1.00
3.00	1.00	0.50	2	1.50
4.00	1.00	0.50	3	2.00
1.00	1.00	1.00	0	1.00
1.50	1.00	1.00	0	1.50
2.00	1.00	1.00	1	2.00
3.00	1.00	1.00	2	3.00
4.00	1.00	1.00	3	4.00

Gabion Baskets Applications:

1. Control and guide of water or flood
2. Flood bank or guiding bank
3. Preventing of rock breaking
4. Bridge Protection
5. Water and soil protection
6. Coast protection
7. Seaport engineering
8. Strengthening structure of soil
9. Protection of road

Advantages of gabion baskets:

1. Monolithic and Flexible structures.
2. Tolerates differential settlement.
3. Uniform wire coating for extra durability.
4. Permeable structures.
5. Pre-assembled units for fast installation and higher quality product.
6. No specialized labor required for installation.
7. Soil Bioengineering

Zinc Coated Weave Wire Mesh Retaining Wall For Creek Slope Projects
